Horizontal Windlass (HWC 2500) Hydraulic SCW/SD(port)
Horizontal Windlass (HWC 2500) Hydraulic SCW/SD(port)

Horizontal Windlass (HWC 2500) Hydraulic SCW/SD(port)

No reviews yet
Part Number:
The HWC Series is designed for automatic horizontal handling of chain-only anchor rodes while offering an independent capstan for the retrieval of a secondary rope and chain rode or to assist with docking procedures.

Features and benefits
  • Fully automatic single or dual direction chainwheel operation, for use with chain only rodes
  • Functional rope hauling from fore and aft using independent fluted stainless steel snag-free warping drum with clutch disengagement of chainwheel for positive control of all ropes
  • Optional dual anchor handling with smooth independent control of each chainwheel via cone clutches
  • Chain pipe assembly supplied
  • Cone-type clutch/brake mechanism permits manual ‘free fall’ anchoring. Cone clutches, unlike dog clutches, provide smooth progressive engagement ensuring safe and precise operator control
  • Chainwheel locking pawl to assist when using warping drumindependently
  • Simple deck mounted installation with no under deck parts
  • Simplified maintenance with ability to strip the running gear (chainwheel and drum) from the windlass without disturbing the windlass mounting
  • Heavy duty, dual direction motor, designed for marine winches
  • Chainwheel and warping drum of high-quality chrome finish over marine-grade bronze
  • Marine-grade alloy casing pretreated, powder coated and finished with a two component white polyurethane paint

    Model HWC 2500
    Maximum Pull/Lift 1135 kg / 2500 lbs
    Static Hold 2200 kg / 4840 lbs
    Chain Short Link 9-11mm / 3/16”- 3/8”
    Line Speed (Normal Working) 15 m/min / 50 ft/min
    Power Supply (DC) No
    Motor (Power) 1200 W
    Net Weight - DC 55 kg / 121 lbs
    Hydraulic Pressure 135 bar / 1950 psi
    Hydraulic Flow 36 l/min / 9.5 USgal/min
    Net Weight - Hyd 48.5 kg / 107 lbs

    Model HWC 2500

    495 mm
    19 1/2”

    289 mm
    11 3/8”

    516 mm
    20 5/16”
    (Hole centres)
    234 mm
    9 1/4”
    (Hole centres)
    278 mm
    10 15/16”
    (Approximate hole centres)
    300 mm
    11 13/16”
    (Working height of drum for rope warping)
    60 mm
    2 3/8”

    125 mm
    4 15/16”

    194 mm
    7 5/8”

    Important: Maxwell windlasses must be used in conjunction with a chain stopper or alternative snubbing device to take the load off the windlass while laying at anchor. The chain stopper and alternative snubbing system should also be used to secure the anchor in the fully raised position while under way.
